Power Plant Sensor Placement Game

Drag the temperature, pressure, and flow sensor symbols onto the correct areas of the plant. This version is touch-friendly, browser-ready, and built on your exact generated power plant image.

Placed: 0/7

Attempts: 0

Correct: 0

Mistakes: 0

Excellent — all sensors are in the correct locations.

Sensor Symbols

Temperature
Boiler, casing, and process line measurement

Pressure
Gauge and pressure tapping locations

Flow
Inline flow sensing on process pipes

Instructions

Drag a sensor card onto a matching blank label area. Correct drops snap into place. Wrong drops return to their start location.

Tip: This page uses pointer events rather than basic HTML drag-and-drop, so it works more reliably on mouse and touch devices.
